A coil has an area of 0.05 m2 and it has 800 turns. It is placed perpendicularly in a magnetic field of strength 4x10-5 Wb/m2, it is rotated through 90° in 0.1 sec. The average e.m.f. induced in the coil is

Question:

A coil has an area of 0.05 m2 and it has 800 turns. It is placed perpendicularly in a magnetic field of strength 4×10-5 Wb/m2, it is rotated through 90° in 0.1 sec. The

average e.m.f. induced in the coil is

Options :

(a) 0.056 V
(b) 0.046 V
(c) 0.026 V
(d) 0.016 V

Answer :

(d) 0.016 V

Answer Steps :

Step 1:

Step 2:

Video Tutorial

An alternating voltage source is connected in series with a resistance R and an inductance L. If the potential drop across the resistance is 200 V and across the inductance is 150 V, then the applied voltage is:

A 1 µF condenser is charged to 50 V. The charging battery is then disconnected and a 10 mH coil is connected across the capacitor so that LC oscillations occur. What is the maximum current in the coil ? Assume that the circuit contains no resistance. The capacity of a pure capacitor is 1 F. In d.c. circuits, its effective resistance will be

In an a. c. circuit the instantaneous current and e.m.f. are represented as: I = I0 sin(ωt – π/6) and E = E0 sin(ωt + π /3) respectively. The voltage leads the current by
