A magnetizing field of 1000 A/m produces a magnetic flux of 2.4 * 10 ^ - 5 Wb in an iron bar of cross-sectional area 0.3c * m ^ 2 The magnetic permeability of the iron bar in SI unit is:

Question:

A magnetizing field of 1000 A/m produces a magnetic flux of 2.4 x10^{– 5} Wb in an iron bar of cross-sectional area 0.3c m² The magnetic permeability of the iron bar in SI unit is:

Options :

(a) 8 * 10 ^-4
(b) 2.5 * 10 ^ - 4
(c) 4 * 10 ^ - 4
(d) 5 * 10 ^ - 4

Answer :

Ans :- (a) 8 * 10 ^-4

Answer Steps :

Step 1: –
