Question:

A milli voltmeter of 25 milli volt range is to be converted into an ammeter of 25 ampere range. The value (in ohm) of necessary shunt will be [2012]

Options :

a)0.001
b)0.01
c)1
d)0.05

Answer :

a)0.001

Answer Steps :

Step:-1

Video Tutorial
