A resistance R is to be measured using a meter bridge, student chooses the standard resistance S to be 100Ω. He finds the null point at 1₁ = 2.9cm. He is told to attempt to improve the accuracy. Which of the following is a useful way?

Question:

A resistance R is to be measured using a meter bridge, student chooses the standard resistance S to be 1002. He finds the null point at 1₁ = 2.9cm. He is told to attempt to improve the accuracy. Which of the following is a useful way?

Options :

a)He should measure l1 more accurately
b) He should changes S to 1000Ω and repeat the experiment
c) He should changes S to 3Ω and repeat the experiment
d)He should given up hope of a more accurate measurement with a meter bridge

Answer :

c) He should changes S to 3Ω and repeat the experiment

Answer Steps :

Step:-1

Step:-2

Video Tutorial

An alternating voltage source is connected in series with a resistance R and an inductance L. If the potential drop across the resistance is 200 V and across the inductance is 150 V, then the applied voltage is:

A 1 µF condenser is charged to 50 V. The charging battery is then disconnected and a 10 mH coil is connected across the capacitor so that LC oscillations occur. What is the maximum current in the coil ? Assume that the circuit contains no resistance. The capacity of a pure capacitor is 1 F. In d.c. circuits, its effective resistance will be

In an a. c. circuit the instantaneous current and e.m.f. are represented as: I = I0 sin(ωt – π/6) and E = E0 sin(ωt + π /3) respectively. The voltage leads the current by
