Question:

A series combination of N₁ capacitors (each of capacity C₁) is charged to potential difference ‘3V’. Another parallel combination of N₂ capacitors (each of capacity C₂) is charged to potential difference ‘V’. The total energy stored in both the combinations is same. The value of C₁ in terms C₂ is

Options :

(a) C2 N1^2 N2^2/9
(b) C2 N2/9N1
(c) C2 N1 N2/9
(d) C2 N1/9N2

Answer :

(c) C₂ N₁ N₂/9

Answer Steps :

step 1

Video Tutorial
