A straight rod of length L extends from x = a to x=L+a. The gravitational force it exerts on a point mass 'm' at x = 0 , if the mass per unit length of the rod is A+ Bx², is given by

Question:

A straight rod of length L extends from x = a to x=L+a. The gravitational force it exerts on a point mass ‘m’ at x = 0 , if the mass per unit length of the rod is A+ Bx², is given by

Options :

(a) Gm[A(1/a+L-1/a)-BL]
(b) Gm[A(1/a+L-1/a)+BL]
(c) Gm[A(1/a-1/a+L)+BL]
(d) Gm[A(1/a-1/a+L)-BL]

Answer :

Answer Steps :

step 1

step 2

step 3

step 4

Video Tutorial

An alternating voltage source is connected in series with a resistance R and an inductance L. If the potential drop across the resistance is 200 V and across the inductance is 150 V, then the applied voltage is:

A 1 µF condenser is charged to 50 V. The charging battery is then disconnected and a 10 mH coil is connected across the capacitor so that LC oscillations occur. What is the maximum current in the coil ? Assume that the circuit contains no resistance. The capacity of a pure capacitor is 1 F. In d.c. circuits, its effective resistance will be

In an a. c. circuit the instantaneous current and e.m.f. are represented as: I = I0 sin(ωt – π/6) and E = E0 sin(ωt + π /3) respectively. The voltage leads the current by
