A toroidal ring, made from a bar of length (l) 1 m and diameter (d) 1 cm, is bent into a circle. It is wound tightly with 100 turns per cm. If the permeability of bar is equal to that of free space (Uo), calculate the magnetic field inside the bar (B) when the current (i) circulating through the turns is 100 A. Also determine the self-inductance (L) of the coil. - VgyanHub

Question:

A toroidal ring, made from a bar of length (l) 1 m and diameter (d) 1 cm, is bent into a circle. It is wound tightly with 100 turns per cm. If the permeability of bar is equal to that of free space (Uo), calculate the magnetic field inside the bar (B) when the current (i) circulating through the turns is 100 A. Also determine the self-inductance (L) of the coil.

Options :

Answer Steps :

Video Tutorial
