A wave in a string has an amplitude of 2 cm. The wave travels in the +ve direction of x axis with a speed of 128 m/sec and it is noted that 5 complete waves fit in 4 m length of the string. The equation describing the wave is

Question:

Options :

a) y = (0.02) m sin (7.85 x +1005 t)
b) y = (0.02) m sin (15.7 x-2010t)
c) y=(0.02) m sin (15.7x+2010t)
d) y=(0.02) m sin (7.85 x-1005 t)

Answer :

d) y=(0.02) m sin (7.85 x-1005 t)

Answer Steps :

Step:-1

Step:-2

Step:-3

Video Tutorial

An alternating voltage source is connected in series with a resistance R and an inductance L. If the potential drop across the resistance is 200 V and across the inductance is 150 V, then the applied voltage is:

A 1 µF condenser is charged to 50 V. The charging battery is then disconnected and a 10 mH coil is connected across the capacitor so that LC oscillations occur. What is the maximum current in the coil ? Assume that the circuit contains no resistance. The capacity of a pure capacitor is 1 F. In d.c. circuits, its effective resistance will be

In an a. c. circuit the instantaneous current and e.m.f. are represented as: I = I0 sin(ωt – π/6) and E = E0 sin(ωt + π /3) respectively. The voltage leads the current by
