Example 12.6: Consider a uniformly wound solenoid having N turns and length 4. The core of the solenoid is air. Find the inductance of the solenoid of N = 200, l = 20 cm and cross-sectional area, A = 5 cm^2 Calculate the induced emf e_{L} if the current flowing through the solenoid decreases at a rate of 60 A/s. - VgyanHub

Question:

Example 12.6: Consider a uniformly wound solenoid having N turns and length 4. The core of the solenoid is air. Find the inductance of the solenoid of N = 200, l = 20 cm and cross-sectional area, A = 5 cm^2 Calculate the induced emf e_{L} if the current flowing through the solenoid decreases at a rate of 60 A/s.

Options :

Answer Steps :

Step 1:

Step 2:

Step 3:

Video Tutorial
