Two conductors have the same resistance at 0°C but their temperature coefficients of resistance are α₁ and α2. The respective temperature coefficients of their series and parallel combinations are nearly [2010]

Question:

Options :

a)α₁+α2/2 , α₁+α2/2
b)α₁+α2/2 , α₁+α2
c)α₁+α2 , α₁+α2/2
d)α₁+α2, α₁α2/α₁+α2

Answer :

a)α₁+α2/2 , α₁+α2/2

Answer Steps :

Step:-1

Step:-2

Step:-3

Step:-4

Video Tutorial

An alternating voltage source is connected in series with a resistance R and an inductance L. If the potential drop across the resistance is 200 V and across the inductance is 150 V, then the applied voltage is:

A 1 µF condenser is charged to 50 V. The charging battery is then disconnected and a 10 mH coil is connected across the capacitor so that LC oscillations occur. What is the maximum current in the coil ? Assume that the circuit contains no resistance. The capacity of a pure capacitor is 1 F. In d.c. circuits, its effective resistance will be

In an a. c. circuit the instantaneous current and e.m.f. are represented as: I = I0 sin(ωt – π/6) and E = E0 sin(ωt + π /3) respectively. The voltage leads the current by
